40μm Opaque White PE Release Film Silicone UV Cured for Protective Packaging and Labeling

Products

High Density Polyethylene Film

Mono Oriented Polypropylene Film

Volatile Corrosion Inhibitor Film

40μm Opaque White PE Release Film Silicone UV Cured for Protective Packaging and Labeling

MOQ:	10000 square meters
Standard Packaging:	PE wrapping film, bubble film, processed wooden pallet
Delivery Period:	within 10 days
Payment Method:	T/T,L/C
Supply Capacity:	500 per month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Model Number

40OWPES

Material:

High Density Polyethylene

Color:

White, Customized

Transparency:

Opaque

Thickness Deviation:

Plus Minus 5 μm

Width Range:

Up To 2000 Mm

Winding Length:

5000 Meters Or So, Customized

Sleeve ID:

3" Or 6"

Thickness:

40 μm

Minimum Order Quantity:

10000 square meters

Packaging Details:

PE wrapping film, bubble film, processed wooden pallet

Delivery Time:

within 10 days

Payment Terms:

T/T,L/C

Supply Ability:

500 per month

Highlight:

opaque PE release film silicone UV cured

40um opaque white PE release films

PE release films 2m

Product Description

40μm Opaque White PE Release Films

40 μm opaque white PE release film, silicone UV cured, designed for protective packaging, tapes, labeling, and graphics applications. This 40 micron opaque white PE silicone coated release film serves as a reliable release liner in the manufacturing of various adhesive products.

The opaque white color provides a solid, non-transparent surface that effectively conceals the adhesive or product underneath. The silicone coating ensures a non-stick surface for easy release during product assembly or application.

Key Applications

Tape Production: Used as a liner for adhesive tape products including double-sided tape, masking tape, and duct tape. The opaque white release liner conceals adhesive and ensures clean product appearance.
Label Production: Serves as a liner for self-adhesive label products, providing visual appeal by concealing the adhesive layer.
Automotive Applications: Used in protective films for painted surfaces and vehicle wrapping applications. Reduces visibility of adhesive residue and maintains clean appearance.
Medical Applications: Employed in wound dressings, adhesive patches, and transdermal drug delivery systems. Minimizes visibility of adhesive residue.
Electronics: Used in electronic manufacturing for protective films on screens and touch panels. Provides clean, unobstructed view of electronic products.

Manufacturing Process

Silicone Coating Process

Film Preparation: Surface preparation through cleaning and treatment with corona discharge or plasma to enhance surface energy.
Silicone Application: Applied using spraying, dipping, or roll coating methods with specific viscosity and concentration for even coverage.
Silicone Curing: Cured at high temperatures (above 120°C) for uniform curing and optimal adhesion to PE substrate.
Trimming & Die-Cutting: Coated PE film is trimmed to correct size or cut into desired shapes using specialized equipment.

Technical Specifications

Parameter	Requirement	Results
Appearance	No air bubbles / stains / breakage / impurities	-
Size - Width (mm)	960 ± 5	962
Size - Thickness (mm)	0.040 ± 0.005	0.042
Max. Tension (N / 50mm) - TD	≥ 30	44
Max. Tension (N / 50mm) - MD	≥ 30	52
Color	White △E＜ 3	ok
Elongation @ break (%) - TD	≥ 150	594
Elongation @ break (%) - MD	≥ 200	479
Surface Tension (Corona treatment)	Dyne Value ≥42 dyne for each side	46
Release Force (gf/25mm 20min.Finat 10) - Inner	5-10	7
Release Force (gf/25mm 20min.Finat 10) - Outer	20-30	24
Subsequent Adhesion (%) - Inner	≥85	88
Subsequent Adhesion (%) - Outer	≥85	90
Winding direction	Customized	-
Splice No.	≤1	-

UV Curing Advantages

UV curing method uses ultraviolet light to initiate chemical reactions in silicone, causing it to cure and crosslink. This modern approach offers several benefits over traditional heat curing methods:

Faster Curing Time: Cures silicone coating in just seconds compared to traditional methods.
Energy-Efficient & Eco-Friendly: Lower carbon footprint with reduced energy consumption.
High-Quality Coating: Results in uniform silicone coating with excellent adhesion and chemical resistance.
Reduced Production Time: Faster processing enables increased production efficiency.
No Heat Damage: Preserves substrate properties without thermal degradation.
