23μm Translucent Blue Anti Static Coated PET Film for Electronics and Medical Packaging

MOQ:	30000 s.q.m.
Standard Packaging:	EPE film + PE wrap + Processed wooden pallet
Delivery Period:	within 45 days, depends on the reserve of raw materials
Payment Method:	T/T,L/C
Supply Capacity:	30000 kg per week

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Model Number

23B1AS-SS

Material:

Polyethylene Terephthalate

Color:

Transparency:

Translucent

Thickness:

23 μm

Thickness Deviation:

Plus Minus 3 μm

Width Range:

Up To 1360

Sleeve ID:

Winding Length:

16000 Meters Or So

Minimum Order Quantity:

30000 s.q.m.

Packaging Details:

EPE film + PE wrap + Processed wooden pallet

Delivery Time:

within 45 days, depends on the reserve of raw materials

Payment Terms:

T/T,L/C

Supply Ability:

30000 kg per week

Highlight:

23 micron Anti Static Film

Translucent Blue coated pet film

23 micron coated pet film

Product Description

23μm Anti Static Film Translucent Blue Coated PET Film

23 μm Blue PET anti static film, available in many colors, for electronics, medical, automotive and printing applications.

Technical Specifications

S/N	Item	Value	Test Method
1	Backing Film Type	Blue PET	DIN EN ISO 10677
2	Release Force (gf/25mm)	8	DIN EN 1464
3	Sub-sequent Adhesion Rate (%)	89	DIN EN 1943
4	Total Thickness (μm)	23	DIN EN ISO 4593
5	Sheet Resistance	10^6-10^11 Ω/sq	DIN EN 1149-1
6	Tensile Strength	MD: 186 MPa TD: 197 MPa	DIN EN ISO 527-3
7	Elongation @ break (%)	MD: 91% TD: 87%	DIN EN ISO 527-3

Industry Applications

Electronics

PET anti-static coated film is commonly used in the production of electronic components and devices to prevent static discharge, which can cause damage to sensitive circuits and components.

Medical

Used in medical packaging to prevent the buildup of static electricity, which can attract dust and other contaminants that can compromise the sterility of medical products.

Automotive

Anti-static coated film can be used in the manufacture of automotive parts and components that require protection against static discharge.

Printing

PET anti-static coated film is used in the printing industry to prevent static electricity buildup on the film during the printing process, which can cause issues with ink adhesion and other printing problems.

Tape Industry

Clear PET anti-static film is also commonly used in the tape industry for the manufacture of adhesive tapes, where it serves as the release liner, and helps to prevent static buildup within the tape rolls.

Specific Application Scenarios

Electronics Testing and Quality Control: Protective layer for electronic components during testing and inspection
Optical Lens and Display Protection: Transparent anti-static layer for optical surfaces
Print and Graphic Design Applications: Protective layer for printed materials with visual enhancement
Medical and Healthcare Equipment: Protective covering for medical devices and instruments
Museum and Artifact Preservation: Protective layer for delicate artifacts and historical documents

Note: Specific suitability should be verified based on industry requirements and manufacturer guidelines.

Key Features

The main feature of PET anti-static coated film is its ability to prevent the buildup of static electricity. It has a conductive coating on one or both sides of the film, which allows charges to dissipate and prevents static buildup. This results in improved handling, processing, and protection of sensitive components and products.

The film is commonly available in transparent or translucent colors, with blue, pink, and yellow variants used for identification and quality control purposes.

Manufacturing Process

PET film is unwound from its original roll and passed through a coating applicator that applies antistatic fluid using methods such as gravure, reverse gravure, Mayer rod or air knife. The coated film is then dried in an oven to remove solvents before being rewound onto new rolls.

Process effectiveness depends on antistatic fluid type and compatibility with PET film, requiring careful control for consistent coating thickness and quality.

Product Images
