36μm Blue PET Anti Static Film for Medical Device Packaging and ESD-Safe Workstations

Products

High Density Polyethylene Film

Mono Oriented Polypropylene Film

Volatile Corrosion Inhibitor Film

36μm Blue PET Anti Static Film for Medical Device Packaging and ESD-Safe Workstations

MOQ:	30000 s.q.m.
Standard Packaging:	EPE film + PE wrap + Processed wooden pallet
Delivery Period:	within 45 days, depends on the reserve of raw materials
Payment Method:	T/T,L/C
Supply Capacity:	30000 kg per week

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Model Number

36B1AS-SS

Material:

Polyethylene Terephthalate

Color:

Transparency:

Translucent

Thickness:

36 μm

Thickness Deviation:

Plus Minus 3 μm

Width Range:

Up To 1360

Sleeve ID:

Winding Length:

8000 Meters Or So

Minimum Order Quantity:

30000 s.q.m.

Packaging Details:

EPE film + PE wrap + Processed wooden pallet

Delivery Time:

within 45 days, depends on the reserve of raw materials

Payment Terms:

T/T,L/C

Supply Ability:

30000 kg per week

Highlight:

36um blue PET anti static protective film

Medical Device Packaging anti static protective film

36um blue PET protective film

Product Description

36μm Blue PET Anti-Static Protective Film for Medical Device Packaging

36 μm blue PET anti-static film, available in multiple colors, designed for electronics, medical, automotive, and printing applications.

Technical Specifications

S/N	Item	Value	Test Method
1	Backing Film Type	Blue PET	DIN EN ISO 10677
2	Release Force (gf/25mm)	8	DIN EN 1464
3	Subsequent Adhesion Rate (%)	89	DIN EN 1943
4	Total Thickness (μm)	36	DIN EN ISO 4593
5	Sheet Resistance	10^6-10^11 Ω/sq	DIN EN 1149-1
6	Tensile Strength	MD: 191 MPa TD: 202 MPa	DIN EN ISO 527-3
7	Elongation @ Break (%)	MD: 114% TD: 103%	DIN EN ISO 527-3

Application Areas

Semiconductor Manufacturing: Protects sensitive components during fabrication, assembly, and transportation with easy blue color identification for efficient workflows.
ESD-Safe Workstations: Provides static-free work surface covering for electronics repair and assembly, ensuring controlled ESD-safe environments.
Automotive Electronics: Shields electronic control units, wiring harnesses, and dashboard displays from static-related damage with color-coded identification.
Medical Device Packaging: Protects static-sensitive medical equipment and devices while enabling easy inventory management through color recognition.
Art Conservation: Safeguards delicate artworks and artifacts from static-related dust attraction and surface disruptions.

Note: Suitability for specific applications should be verified based on industry requirements and manufacturer guidelines.

Key Features

PET anti-static coated film prevents static electricity buildup through conductive coating on one or both sides, allowing charges to dissipate effectively.

This results in improved handling, processing, and protection of sensitive components and products. While transparent or translucent films are common, colors like pink, blue, and yellow are available for identification and quality control purposes.

Manufacturing Process

The coating process involves unwinding PET film and applying antistatic fluid through gravure, reverse gravure, Mayer rod, or air knife methods, followed by drying oven solvent removal and rewinding.

Process effectiveness depends on antistatic fluid type and PET film compatibility, with careful control required for consistent coating thickness and defect-free final products.

Product Images
