50um Clear PET Non Silicone Release Film For Electronics

50um Clear PET Non Silicone Release Film For Electronics

MOQ: 30000 s.q.m.
Standard Packaging: EPE film + PE wrap + Processed wooden pallet
Delivery Period: within 45 days, depends on the reserve of raw materials
Payment Method: T/T, L/C
Supply Capacity: 30000 kg per week
Detail Information
Place of Origin
China
Brand Name
HSF
Certification
ISO, SGS, RoHS
Model Number
50TSSNSi
Material:
Polyethylene Terephthalate
Color:
Natural
Transparency:
Clear
Thickness:
50 μm
Thickness Deviation:
Plus Minus 3 μm
Sleeve ID:
6"
Winding Direction:
Release Side Wound In, Or As Per Requirement
Winding Length:
6000 Meters Or So
Minimum Order Quantity:
30000 s.q.m.
Packaging Details:
EPE film + PE wrap + Processed wooden pallet
Delivery Time:
within 45 days, depends on the reserve of raw materials
Payment Terms:
T/T, L/C
Supply Ability:
30000 kg per week
Highlight:

50um Clear PET Non Silicone Release Film

,

50um Clear PET release film

,

pet release film for electronics

Product Description

50 μm Clear PET non silicone coated release film for electronics, medical, automotive and printing etc.

Clear PET non-silicone coated release film is a type of film that is used in a variety of applications where a release liner is required.
This film is typically made from clear polyester (PET) that is coated with a non-silicon release agent on one side.

Here are some common applications for clear PET non-silicon coated release film:

1. Labels:
    The film is used as a backing material for labels, stickers, and decals.
    The non-silicone release coating allows the label to easily separate from the backing, so it can be applied to the desired surface.

2. Medical devices:
    The film is used as a liner for medical devices, such as wound dressings or transdermal patches.
    The non-silicone coating prevents any contamination from the release liner, which is important for maintaining sterility.

3. Packaging:
    The film can be used as a release liner for packaging materials that need to be easily opened, such as pouches or bags.
    The clear PET film allows the contents to be visible while also providing a barrier against moisture and other contaminants.

4. Electronics:
    The film is used as a release liner for electronic components, such as adhesive tapes or protective films.
    The non-silicone coating prevents any damage or interference to the electronic device during the release process.

*   Clear PET non-silicon coated release film is a versatile material that is used in a wide range of applications where a reliable
    release liner is needed.

Besides, the application of non-silicon release film is mainly based on two points:
1. It does not contain silicon, so there are no issues with silicon transfer contamination.
2. It is compatible with silicone and gel, and is cheaper than fluorine-coated film
    (although the release effect is not as good as fluorine-coated film).

S/NTest ItemUnitStandardValueTest Method
1Thicknessμm50 ±2%49.72GB/T6672
2Color-Transparent--
3Tensile StrengthMDMpa≥180187GB/T 1040.3
TDMpa≥190196
4Elasticity ModulusMDMpa/4144
TDMpa/4230
5Elongation @ break (%)MD%≤200148
TD%≤200139
6Thermal ShrinkageMD%≤1.50.96150℃/30min
TD%≤0.00.00200℃/10min
7Friction CoefficientF/M-US%≤0.650.5GB/T 10006
F/M-UK%≤0.500.3
8Haze%≤52.99GB/T2410
9Luminousness%≥8689.4GB/T2410
10Glossiness%≥100133GB/T8807
11Wetting TensionmN/m≥5058GB/T14216
12Release ForceInnergf/25mm3-54Final 10, 20min.
Outer10-1512
13Sub-sequent Adhesion RateInner%≥8590
Outer≥8592


50um Clear PET Non Silicone Release Film For Electronics 050um Clear PET Non Silicone Release Film For Electronics 1
